Bond's Catalogues
1937-1938. Bond's Model and Experimental Engineering Handbook
1938, 2nd Edition. Bond's Model and Experimental Engineering Handbook
1939-1940. Bond's Model and Experimental Engineering Handbook
1946-1947. Bond's Model and Experimental Engineering Handbook
1969. Stuart Models Catalogue

On Amazon:



Bond's Model Engineering Catalogues

About Bond's:
Bond's was a renowned model engineering shop who described themselves as 'Makers and Suppliers of Models and Light Engineering Equipment' and were located at:
357 Euston Road, London NW1, and was founded in 1887. No. 357 was their new premises - they had previously been located on the north side of the Euston Road between Hampstead Road and George Street. There's a little map in the September 1937 catalogue on page 2 showing the locations of the new and old shops.
In 1937 and 1938, their directors were S. D. Phillips and S. C. Phillips, Office Tel. Euston 5441-2. Business hours were 9a.m. to 7.30 p.m. and on Thursdays from 9 a.m. to 1 p.m. They put out regular catalogues to their customers; and were involved in making and supplying working models, as well as in retailing lathes, parts, materials and know-how for customers to make their own models, parts, boilers and engines (and more besides)



Phillips, S. D; and Phillips, S. C. 'Bond's Model and Experimental Engineering Handbook 1937-1938', 1st Edition, published in September 1937, in paperback by Bond's o' Euston Road, 200pp. Sorry, sold out, but click image to access a prebuilt search for this title on Amazon UK
September 1937, Bonds o' Euston Road, pbk
Sorry, sold out, but click image above to access a prebuilt search for this title on Amazon UK

Alternative online retailers to try:
Click here to access our prebuilt search for this title on Abebooks

Click here to access our prebuilt search for this title on Alibris

Click here to access our prebuilt search for this title on Ebay

Click here to access our prebuilt search for this title on Biblio

AbeBooks.co.uk

Find this book at Biblio.com!

About this book/synopsis: The catalogue contains practically all of Bond's model stock as it stood at the time of publication in September 1937. Bond's stated in their catalogue that this selection was one of the most comprehensive in the world. Bonds prided themselves on stocking everything that would be of interest to the model engineer whether they were interested in railways, ships, internal combustion engines or any other branch of engineering from the smallest nut and bolt or rough materials, to some of the finest finished working models made at that time by any model makers.

Bond's makes much of their 'new' showrooms on page 3 of the catalogue, so it can be safely assumed that the move to the new premises at 357 Euston Road had occurred not long before this September 1937 catalogue was published. Bond's emphasised that the new workshops were completely equipped with new machinery so that all types of repair work could be undertaken; and any class of model could be built. The turning capacity for their new workshops was 21 inches for wheels down to the smallest screw needed for model work. Bond's specialized in making Model Locomotives and Power Boats, ranging in size from Gauge 00 electric models to 1.25 inch scale coal-fired passenger hauling Locomotives and Power Boats up to 6ft length. They also had multi-gauge track for testing locomotives up to 7.25" gauge

Some Special Models Made in 1937 in Bond's workshops (black & white photographs)
Page 5, top: can be seen pictures of models that Bond's workshops had recently completed such as a working model of a Ransome and Rapier 10-Ton electric travelling Jib Crane with working electric motors for the lifts and turning gear. The model was built to the scale of 1/4 inch to 1 foot
Page 5, middle: Pickfords Removals and Storage van, mounted on a Leyland chassis. Built to a scale of 3/4 inch to 1 ft, it had all external details correctly modelled and painted
Page 5, bottom: LNER 4470, Great Northern, a Class A1 4-6-2 steam locomotive built up to the scale of 1 inch to the foot and used in the making of a film at Elstree, mostly to provide close-up and accident shots. The model had to be exactly correct so that errors would not be evident in the filming
Page 6, top and middle: Silver-plated models of the Rudge Whitworth Motor Cycles (Bike No. 34), winners of the 1930 Junior T.T Races
Page 6, bottom: A silver-plated model of the Vickers-Super-Marine Rolls Royce S.6.B Seaplane, which won the Schneider Trophy for England in 1931, built to a scale of 3/4 inch to one foot. The model Bond's built was an exact replica of the Seaplane as flown in the race

Bond's catalogues features plentiful black and white photographs and illustrations and included helpful advice and tips; and also tremendously detailed lists of items for sale such as model railway locomotives, track, scenery, rolling stock and electric transformers, signals; locomotive castings, technical drawings, lathes, model wagons, coaches and locomotives both steam and electric, with lists of parts available such as wagon axleguards and bolster beams, and so much more

In this edition Bonds have also included hints, tips and advice to all their customers on how to start building a model railway, which gauge to use, how to control points and wiring up electric track; with notes on running clockwork and electric locomotives; and how to address all the signalling. Pages 10 - 16 talk in very general terms about how the reader would approach building a live steam model locomotive and how the components of such a locomotive are typically manufactured, e.g. "Axles are turned from mild steel..." and "The first step before the actual construction begins is to obtain drawings of the proposed model..."

Model boats and yachts are very briefly mentioned on pages 16 - 17; with tools and workshop notes on pages 17-21 where Bond's tells the aspiring model engineer what they will need to equip a workshop in order to be able to handle advanced work: "The most useful size model worker's lathe is from 3 inches to 4 inches centre height. To equip this you will want the following in order of preference as the exchequer's pocket allows: - 4-jaw chuck, tool holder with high speed bits; and then as required 3-jaw chuck, tailstock drill chuck, tailstock die holder, lathe carriers, small boring tools and a vertical slide for small milling work. Other machines that should be installed in the following order as required are: a drilling machine, grinding head, milling machine and shaping machine." The section includes notes on fitting a chuck to a lathe, soldering and brazing and useful tips such as "To case-harden mild steel get steel red hot and dip into "Kasenit" powder, re-heat and repeat about three times, then drop vertically into cold water in the same way as ordinary hardening"

p20. Top table. Screw cutting chart for any lathe with leadscrew 8 threads per inch. Table includes columns: Threads (8 to 60 and then Self-Act 118.8); Head Spindle; First Stud; Second Stud and Lead Screw number
p20. Middle table. Standard wire or metal gauge equivalents - contains the same columns as the top table
p20. Bottom table. Decimal equivalent or the number size twist drills - includes the columns: No. (from 1 to 80); Size of No. in Decimals (inches - runs from .2280 to .0135)
p21. Table of Decimal Equivalents of 8ths, 16ths, 32nds, and 64ths of an inch



Model Engineering in the 20th Century


Workshop Tools


Bond's Model and Experimental Engineering Handbook, 1938 2nd Edition, 203pp. Sorry, sold out, but click image to access prebuilt search for this title on Amazon!
1938, Bond's o' Euston Road, pbk
Sorry, sold out, but click image above to access a prebuilt search for this title on Amazon UK

Alternative online retailers to try:
Click here for our prebuilt search for this book on Abebooks

Click here for our prebuilt search for any edition of this book on Alibris

Click here for our prebuilt search for this book on Ebay

About this catalogue: Bond's put out regular catalogues to customers, featuring helpful advice and tips; and also tremendously detailed lists of items for sale such as locomotive castings, technical drawings, lathes, model wagons, coaches and locomotives both steam and electric, with lists of parts available such as wagon axleguards and bolster beams, and so much more. In this edition, Bond's give hints and tips for the model railway owner such as what gauge to use and how to lay track, with notes on point control and wiring up electric track. There are notes on running clockwork and electric locomotives, lists of useful books, an article on steam model locomotives, valve gears, useful books for the steam locomotive builder, hints on steam fittings, suitable plant for boats, yachts, useful books for the boat builder, tools and workshop notes, fitting a chuck to a lathe, solderings and brazings, screw cutting chart for any lathe with leadscrew 8 threads per inch, a table on standard wire or metal gauge equivalents,a table on decimal equivalent of the number size twist drills, and table of decimal equivalents. There then follows an article on model track for a couple of pages, which leads into the actual catalogue. Indexed
Phillips, S. D.; Phillips, S. C. 'Bond's Model and Experimental Engineering Handbooks 1939-1940' published in 1939 by Bond's o' Euston Road, 208pp, no ISBN. Sorry, sold out, but click image to access a prebuilt search for this title on Amazon UK
1939. Bonds o' Euston Road, pbk
Sorry, sold out, but click image above to access a prebuilt search for this title on Amazon UK

Alternative online retailers to try:
Click here for our prebuilt search for this book on Abebooks

Click here for our prebuilt search for any edition of this book on Alibris

Click here for our prebuilt search for this book on Ebay

About this book/synopsis: This is a handbook and catalogue for the period 1939-1940 by model shop and model engineers Bonds o' Euston Road. Bonds advertised themselves as makers and suppliers of models and light engineering equipment and had been in business since 1887 selling everything of interest to the model engineer such as railways, ships, internal combustion engines or any other branch of engineering. Their workshops were equipped for repair or new build and they specialized in making power boats and locomotives; the prices given in this catalogue were correct as of July 1939. At the start of this catalogue, Bond's have included some useful articles:
1. Some Hints and Tips for Your Model Railway compiled by the Staff of Bonds, including notes on point control and wiring up electric track, notes on running clockwork and electric locomotives, useful books, valve gears, and hints on steam fittings. As with all model railways, this article recognises that lack of space is a key issue and the article mainly concentrates on "00" or "0" gauge. Gauge "00" was usually electric driven even at the time this catalogue was published, whilst for "0" gauge, it seems there were clockwork, electric or steam-driven locos available. Outdoor railways are also examined and gauge "1", 0.5 in. or .75 in. scale or larger are recommended.
The article includes a section on steam locomotives-the high pressure boiler model locomotives (Bonds had made successful high pressure locomotives in all gauges down to gauge "0") and it links nicely in with the subsequent catalogue, pointing readers to the relevant sections for types of burners, drawings and Bond's new half-inch (17/32) scale standard locomotive parts - 2.5 inch gauge supplied either as castings or finished machined parts.
2. Suitable Plant for Boats including yachts, useful boats for the boat builder. This article recommends particular types and size of engines for particular sizes of boat, e.g. Meteor, Star and Ohlsson engines. It focuses on blowlamps and how to get the best of them. The notes on yachts are brief, but it does recommend the best allround sail rig (which is Britannia) and some useful books for the boat builder
3. Tools and Workshop Notes including fitting a chuck to a lathe, soldering and brazing, useful tips. This last chapter includes a screw cutting chart for any lathe with leadscrew 8 threads per inch; standard wire or metal gauge equivalents; decimal equivalent of the number size twist drills; and table of decimal equivalents. Following the charts is a list of useful books for the workshop.
In the very back of this catalogue, prior to the index are a few adverts -books by Percival Marshall; Meccano Magazine; an advert for the 'English Mechanics' magazine; and finally an advert for W. Pritchett, tailor and outfitter at 183-184 Tottenham Court Road, selling 'Model Suits -for Model Engineers', which was 5 minutes walk from Bond's!

Bond's of Euston Road, '1946-1947. Bond's Model and Experimental Engineering Handbook, 96pp, paperback. Sorry, sold out, but click image to access a prebuilt search for this title on Amazon UK
1946. Bond's of Euston Road
Sorry, sold out, but click image above to access a prebuilt search for this title on Amazon UK

Alternative online retailers to try:
Click here for our prebuilt search for this book on Abebooks

Click here for our prebuilt search for any edition of this book on Alibris

Click here for our prebuilt search for this book on Ebay

  • 1946-1947. Bond's Model and Experimental Engineering Handbook [top]
    No author: published as a sales catalogue given out or sent out to customers of the model engineering shop 'Bond's of Euston Road'.
    Published on Dec. 1, 1946 by Messrs Bond's of Euston Road, Ltd., 357 Euston Road, London, NW1, in paperback, 96pp. Originally sold at 1/3 (1 shilling and three pence)

About this catalogue: This copy is somewhat smaller than their usual catalogue size due to post-war rationing and difficult economic circumstances. The Bond's catalogues are of immense importance partly due to their rarity, but also because they tell us today exactly what was available to the model engineer in a given year. For example in the 1946 catalogue, Bond's sold specially drawn blue prints for the amateur to effect a model of locomotives such as the L.M.S Mixed Traffic Loco 13245 Class in Gauge "0"; and drawings of 25-ton Goods Brake Vans, again in "0" gauge. There were even permanent way drawings to help model makers set up special railway layouts. Henry Greenly Blue Print Drawings of Locomotives and J.E. Skinley drawings of railway locomotives and coaches were also on sale, alongside heavier items such as flash steam boilers for racing speed boats and copper centre flue boat boilers
